Product name:

GMP Oven For Medicine Use

Class:

Drying Series

Description:

GMP Oven For Medicine Use Features
* The heat source used for heatinghas steam, electricity,both steam andelectricity there ways .

* Operation temperature:steam,50-140℃;Max,150℃;electricity,50-350℃;oil,150-350℃.

* The temperature can be controlled automatically.Moreover it can be recorded through recorder.

* The inner wall of oven body is welded.Every place of transition adapts circular are and no dead angle.

* The seal property of whole machine is good.Being adapted unique guide rail seal apparatus,the seal property can be guaranteed.

* The air inlet is equipped with high effective air filter and the damp exhaust outlet is equipped with middle effective air filter.

* The double doors of oven can be assembled and disassembled quickly in order to clean conveniently.

* The control system has text display and touch screen for your choice.

* is in conformity with requirements of GMP.


Technical parameters


Typeandspecification

Dry each timea mount(kg)

Power of fan (kw)

Consumed steam (kg/h)

Drying trolly(set)

Baking pan(piece)

W*D*H(MM)

Temperature differece between up and low(℃)

GMP-0

35

0.45

8

0

16

1130*1100*1750

±2

GMP-Ⅰ

120

0.45

18

2

48

2300*1200*2000

±2

GMP-Ⅱ

240

0.9

36

4

96

2300*2200*2000

±2

GMP-Ⅲ

360

1.35

54

6

144

3430*2200*2000

±2

GMP-Ⅳ

480

1.8

72

8

192

4460*2200*2290

±2
